GE Logiq V2 portable ultrasound (system only)

Product Specifications

BRAND	GE Healthcare
MODEL	V2 portable ultrasound

DESCRIPTION

The LOGIQ V2 is a compact designed laptop-style ultrasound imaging system designed for Abdominal, Obstetrical, Gynecological, Small Parts, Vascular/Peripheral Vascular, Urological, Transcranial and Cardiac applications.

ADDITIONAL INFORMATION

General specifications:
Dimensions and weight

Height: 120mm
Length: 396mm
Width: 368mm
Weight: 6kg with battery

Electrical power

Voltage: 100-240 VAC
Frequency: 50/60 Hz
Power consumption:
Maximum of 200 VA with peripherals

Console design

1 in-built active probe port
2nd probe port with optional adapter
Integrated HDD (120GB)
Integrated speakers

User interface

Operator keyboard
Ergonomic full size keyboard
8 TGC Slider segments (pods)

Monitor

15” (381mm) high-resolution LCD (1024 x 768 pixels)
Brightness adjustment

System overview
Applications:

Abdomen
Obstetrics
Gynecological
Cardiac
Vascular
Transcranial
Musculoskeletal
Urological
Small Parts
Pediatric & Neonatal

Scanning methods

Electronic Convex
Electronic Linear
Electronic Sector

Transducer types

Convex Array
Linear Array
Sector Phased Array

Operating modes
• B-Mode
• Coded Phase Inversion Harmonic Imaging
• M-Mode
• Color M Mode
• Color Flow Mode (CFM)
• Power Doppler Imaging (PDI)
• Directional PDI
• PW Doppler with High PRF
• Anatomical M-Mode (Option)
• CW Doppler Mode (Option)

System standard features

AO (Automatic Optimization)
CrossXBeamTM
SRI-HD (High Definition Speckle Reduction Imaging)
B-Steer
Coded Phase Inversion Harmonic Imaging
Virtual Convex
Patient information Database
Image Archive on integrated HDD
Raw Data Analysis (TruScan)
Real-time automatic Doppler calculations
OB Calculations
Fetal Trending
Multi-gestational Calculations
Hip Dysplasia Calculations
Gynecological Calculations
Vascular Calculations
Urological Calculations
Renal Calculations
Cardiac Calculations
Remote capability: InSite ExC
On-board reporting package
MPEGVue
Network Storage

System Options

Auto-IMT
CW Doppler
DICOM® 3.0 Connectivity
Anatomical M-Mode (AMM)
LOGIQ View
Easy 3D (Free Hand 3D)
Scan Assistant
Scan Coach
SonoBiometry

Available probes & applications:

4C-RS Convex Array 2.0 - 5.0 MHz Abdomen, OB/Gyn, Vascular, Urology
8C-RS Convex Array 4.2 - 10.0 MHz Pediatric, Cardiac, Small Parts
L6-12 Linear Array 4.0 - 13.0 MHz Small parts, Vascular, Pediatrics
LK760-RS Linear Array 5.0 - 10.0 MHz Small parts
12L-RS Linear Array 4.2 - 13.0 MHz Vascular, Small Parts, Pediatrics
E8C-RS MicroConvex Array 4.2 - 10.0 MHz OB/Gyn, Urology, Transvaginal
3Sc-RS Phased Array 1.7 - 4.0 MHz Cardiac, Transcranial, Intercostal
