Premium Upright Freezer Model U570, 120 V, 60 Hz

PRODUCT DESCRIPTION

Premium U570 ULT Upright Freezer
The U570 is the second largest upright freezer in the Premium lineup. The U570 will provide years of maintenance-free, reliable operation with minimal energy consumption. The U570 consumes 14.1 kWh/day and pulls down from ambient to set temperature in 5.3 hours, roughly twice as fast compared to similar sized competitive models.  A bright eye level, LED control system is standard along with a 5 compartment, adjustable shelving system which can accommodate any type of racking configuration.
Economical Premium freezers are conventionally-insulated providing a cost effective alternative, with many of the same features and quality as the Innova models. Five models are available U410, U570, U700, C340 and C660.

• 3 large-capacity uprights—for easy access to samples, choose the U410, U570 or larger U700, each with 5 compartments and 4 adjustable-height shelves
• 2 chests—if a chest style is preferred, choose C340 or C660 with insulated sub-lids that provide added sample protection
• Accessories include: Racks, CO2 and LN2 back-up systems and more are available

Hassel-free monitoring system for your ULT freezer
The TCA-3 system is a truly independent temperature monitoring platform for your Ultra-Low Temperature freezer. There is absolutely no software to download and you can generate reports and review alarms within minutes. This is the only system that combines a chart recorder, auto-dialer, alarm system and power monitor into one small pod. In addition, all the data collected by your TCA-3 system can be viewed from any web based computer, always keeping you informed.

Support the epGreen initiative with your New Brunswick ULT freezer
New Brunswick Ultra-Low Temperature freezers are the most energy-efficient in the industry, reducing energy consumption by thousands of kilowatt hours over our competition.

• New High Efficiency Freezers further reduce energy consumption by up to 59% compared to other models of similar size and are 98% recyclable by weight
• A 28 ton reduction of CO2 emissions on average, over the life of each freezer – That’s equivalent to planting 138 earth-cooling, oxygen-replenishing adult trees

Features

• Traditionally foamed Polyurethane insulation provides efficient insulation protection
• Quick pull down and recovery times with reliable heavy-duty compressors
• Easy to read, eye level, flush mounted LED control panel and alarm status with integrated SMART PLUS diagnostics
• SMART PLUS™ diagnostic system displays error codes allowing accurate diagnoses by engineers over the phone, saving you time and money
• Inner doors are insulated minimizing cold air loss while accessing your samples
• 5 compartments, each accepts NBS racks as well as other popular brands without adjustment
• Each shelf is adjustable in height for additional storage flexibility. Each shelf is adjustable in 1/2" increments.
• Unique low temperature outer door seals allow gaskets to remain flexible at –86°C and prevents ice build up
• Full stainless steel interior is easily cleaned and eliminates the possibility of rusting during maintenance and defrost cycles
• Significantly reduced noise levels allowing placement of the freezer virtually anywhere
• Unique vacuum vent with plunger ergonomically located at waist level to gain immediate access to your freezer
• Password protection of alarm and temperature set points to prevent unauthorized setting changes
• Each freezer slides effortlessly through a standard doorway simplifying installation
• Temperature range from –50°C to –86°C
• 2-year warranty covering labor, 5 years covering all parts
