Capture Mini 3D Systems

PRODUCT DESCRIPTION

The Capture™ Mini scanner from 3D Systems delivers accurate and fast blue light 3D scanning technology in a portable, lightweight unit that can be hand-held, static and easily combined into a multi-scanner configuration.
With the optional ProPack, you can seamlessly add hands-free turntable scanning and transport your scanner safely in a high-quality case. The Capture Mini is integrated with Geomagic reverse engineering and 3D inspection software for rapid and highly accurate scan-to-3D processes.

Bring physical objects directly into CAD, supercharge your product development process, and automate precise 3D inspection with Capture - the powerful, integrated, industrial-grade 3D scanner and software system.

Geomagic Capture for Scan-Based Design
ENHANCE YOUR CAD SYSTEM
Reverse engineer with style. Geoagic Capture scanners work flawlessly with SOLIDWORKS® via a software plugins and connects via Geomagic Design X to Siemens® NX™, Solid Edge®, Creo®, Pro/ENGINEER® and Autodesk Inventor®. With the power to take scan data directly into CAD, you can design highly complex parts faster via one seamless workflow.
PROFESSIONAL-GRADE, ACCURATE SCANNING
The ultra-compact Capture scanners capture precise data using state-of-the-art blue LED technology. The amazing devices capture almost one million points in 0.3 seconds to create detailed models of physical objects, accurate to 0.034-0.118 mm.
POWERED BY PROVEN TECHNOLOGY
Capture scanners utilize industry-leading customer-proven technology. With this software, you get the easiest, most powerful scan-based design and reverse engineering software technology combined with proven scanning hardware.
BUILT FOR A VARIETY OF DEMANDING APPLICATIONS
Capture portable scanners and flexible software make it a perfect fit for a variety of applications, from heavy-duty manufacturing to industrial design to automotive to jewelry. The new method of Scan-Based Design empowers designers across all industries to swiftly create the type of innovative products that customers demand.
REDUCE INTEGRATION AND TRAINING COSTS
With Capture scanners you get one easy-to-use, affordable solution that bridges hardware, software and CAD for your convenience. Because it’s a complete plug-and-play system, you won’t have to burn time incorporating multiple products from multiple vendors into your workflow.

Specifications
Capture Mini

• Weight: 1.04 kg
• Dimensions: 155 x 109 x 49 mm
• Data Capture Rate: 985,000 points/scan (0.3 sec per scan)
• Resolution: 0.080 mm at 157 mm, 0.100 mm at 227 mm
• Accuracy: 0.034 mm
• Stand-off Distance: 157 mm
• Depth of Field: 70 mm
• Field of View: 87 x 68 mm (near), 88 x 87 mm (far)
• Computer Requirements: Windows 7/8 (64-bit) Operating System, Intel and AMD Quad-core 2-GHz CPU or better, Gigabit Ethernet interface, 4 GB Memory or greater, 512 MB Video Card or better
