SIFULTRAS-5.31 Handheld Ultrasound Machine

DESCRIPTION

The Wireless Linear Ultrasound Scanner SIFULTRAS-5.31 is portable and handheld. It uses high-frequency ultrasound to create high-resolution images of structures near the body surface. This makes the probe ideal for vascular imaging and certain procedures such as central line placement.

The Wireless Linear Ultrasound Scanner SIFULTRAS-5.31 is mainly used to examine the circulation in the blood vessels of the body.
Further, the Wireless Linear Ultrasound Scanner SIFULTRAS-5.31 can be used to evaluate arteries or veins in nearly any part of the body, including blood vessels in the neck, abdomen, arms, and legs.


ADDITIONAL INFORMATION

Wireless Linear Ultrasound Scanner SIFULTRAS-5.31, applications:

• Accurate needle placement for procedures such as a peripherally inserted central catheter (PICC), intravenous injection (IV), vein finder prior to injection, and especially joint injections and Musculoskeletal and for ORTHOPEDIC doctors.
• Evaluation of blood flow in the arteries and veins.
• Detect the presence, severity, and specific location of the disease.
• Diagnose narrowing of arteries and determine the severity of narrowing.
• Diagnose blood clots in the veins of the arms and legs.

       Features :

• Workable with Tablet or Smartphone.
• Built-in and replaceable battery.
• Advanced digital imaging technology, clear image.
• High cost-effective.
• Wireless connectivity, easy to operate.
• Small and light, easy to carry.
• Applicable in the emergency, clinic, outdoor and vet inspection.
• The intelligent terminal platform, powerful expansion functions on the application, storage, communication, and printing.

       Specifications :

• Scanning system: Electronic array scanning.
• Frequency:  7.5MHz.
• Wireless Linear Ultrasound Scanner SIFULTRAS-5.31.
• 128 Elements.
• Depth: 20 mm ~ 100 mm, Adjustable.
• Field of view(convex array) : 80 degree.
• Screen: Smartphone or tablet screen.
• Supporting system: Apple iOS & Android. Tablet or Smartphone. (Windows system coming soon).
• Display mode: B.
• Frame rate : 12f/s.
• Image grayscale: 256 level.
• Image Storage:  intelligent terminal (mobile phones, Tablet PC) storage devices.
• Suitable for MSK, abdomen organs ultrasound scanning, Dry needling…
• Power: by a built-in battery.
• Power consumption : 10W (unfreeze) /4W (freeze).
• Battery working time : 3 hours.
• Size : 156mm×60mm×24mm.
• Weight: 308 grams.

Certifications:

• FDA
• CE
• ISO13485

Wireless Linear Probe Ultrasound Scanner 7.5Mhz SIFULTRAS-5.31

Frequency : 7.5 MHz.

Depth : 20mm ~ 100mm.

Battery Last : 3 hours (Scan Mode) – 6 Hours (freeze mode).

Application: Thyroid, Breast, Vascular, Nerve, MSK (Musculoskeletal).

Certifications: FDA, CE, ISO13485
