Radiodetection LMX100 Portable Ground Penetrating Radar

Product Specifications

BRAND	Radiodetection
MODEL	LMX100

DESCRIPTION

LMX100™ completes the locator’s toolbox, offering a more complete picture of the underground infrastructure. With a simple, easy-to-use interface it also offers the perfect balance of depth penetration and high resolution for accurate locating.
LMX has the advantage of detecting:

Metallic and non-metallic utilities
Utilities with broken tracer wires
Undocumented utilities
Trenches and disturbed soil often associated with utility burial
Unexpected obstacles or buried structures such as old foundations that can cause problems for excavations or construction

ADDITIONAL INFORMATION

FEATURES:
LMX100 Portable GPR
110 Volt Charger
System Size (L x W x H)100 cm x 70 cm x 115 cm (39.4 x 27.6 x 45.3 inches)
System Weight22 kg (48 lbs)
GPR Sensor size630 × 410 × 230 mm (25 × 16 × 9 in)
GPR Sensor weight5 kg (11 lbs)
Display Unit weight2.83 kg (6.24 lbs)
Screen8.0″ diagonal, high-visibility touch screen LCD color display
• Adjustable backlighting
• 1500 NIT and 800:1 contrast ratio
WirelessIntegrated modules: Wi–Fi (IEEE 802.11 b,g,n)
GPS/GLONASS
AudioBuilt–in speaker–85dBA speaker w/volume control
Battery12 Volt Lead acid gel cell
Battery Capacity: 9.0 Ah
Battery Life: 4–6 hours
Weight: 3.6 kg (7.9 lbs)
ChargerCharger with status indicator
Universal AC mains charger input: 100-240V, 1.5A, 50/60Hz
Output: 12 Volts @ 3 Amps
Temperature & EnvironmentalRuggedized, environmentally sealed unit and connections.
Ingress protection (IP) rating of the Display Unit is IP65 under IEC 60529
Relative Humidity operation (non–condensing): 10–90%
Operating temperature range: −40 to 50℃
Do not use touchscreen below −20 C
Regulatory SpecificationsEMC–FCC, IC, ACA, RSM
Safety–TUV, CE
