LabTech MultiVap54 is the latest automatic nitrogen evaporator that is able to process up to 54 samples simultaneously. This advanced instrument allows automatic control of both the nitrogen flow rate and the vertical lift of nitrogen needles. These unique features can greatly speed-up the vapour removal and maximize the solution surface area in contact with nitrogen gas, thus significantly saving nitrogen gas consumption and improving evaporation efficiency. Meanwhile, MultiVap54 water bath temperature and N2 gas flow rate can be adjusted during the evaporation process depending on solvent boiling point and volatility.
Technical features:
- 54 sample positions able to work either individually or simultaneously
- Automatic adjustment of nitrogen needle according to the sample volume reduction
- Visible concentration process thanks to the front window and internal lights
- Auto-locked cover during operations
- Easy replacement of nitrogen needles
- 7” touch-screen color control panel
- Low-level liquid level alarm
- Intuitive software interface
P/N: US-MP5000 Description
MV5 Evaporation/Concentration System
Each complete package includes :
·MV5 Evaporator Unit, 54 position
·6 x Nitrogen blowing tool kit incl. needles and o-ring seals
·10 x 19G Nitrogen blowing needle, 10pcs/pack
·6 x Nitrogent blowing sealing ring, 6pcs/pack
·1 x Exhaust pipe, 3m/pc
Draining tool kits Includes:
- Plug, 54pcs/pack
- Hose clamps
- Tool kits
- Nitrogen joint assembly kits
- PU tube,5m
Power Supply: 230V, 50/60Hz
Unique Features
·Up to 54 tube‐capacity
·Automatic nitrogen pressure profiling
·Water bath ‘low’‐level sensor protects heater life
·Integrated, easily accessible water bath drain
·Autolocking door during operation
·Low‐flow gas control
