Key Features & Specifications:
- Up to 160 MHz modulation and signal capture bandwidth
- 512 Msa playback and signal capture memory per channel
- Up to 6 BBGs and 16 faders for interference, diversity and MIMO test
Standards compliant signal creation
* Run Signal Studio software on the PXB in a familiar Windows environment
* LTE, HSPA, W-CDMA, GSM/EDGE, TD-SCDMA, Mobile WiMAX, WLAN, digital video, GPS, GLONASS, and DC-HSPA with 8960 (E5515C) wireless communication test set
* Real-time uplink LTE FDD and LTE TDD signal creation for 3GPP eNB receiver verification tests
* Connect with SystemVue software or play back your own MATLAB waveforms
Advanced channel emulation
* Fade RF, digital I/Q, ESG and PXB generated signals
* Up to 160 MHz fading bandwidth or 24 paths per fader
* Single channel, dual channel, 1x2, 1x4, 1x8, 2x1, 2x2, 2x4, 2x6, 4x2, 2x8 and 4x4 MIMO
* Connect to the 8960 Series 10 (E5515C) wireless communication test set
Comprehensive channel correlation settings
* Select standard-based channel models or modify them for the latest wireless formats
* Calculate correlation coefficients based on antenna setup
* Input correlation coefficients into custom correlation matrix
* LTE channel models for MIMO OTA test including SCME Urban Micro-Cell, Macro-Cell, and WINNER II
