Unit SpecificationsPrime Rating100 kW125 kVA
Standby Rating110 kW137 kVA
Generator RPM1800
Voltage - Three Phase208, 220, 240, 416, 440, 480V Switchable
Voltage - Single Phase120, 127, 139, 240, 254, 277V Switchable
Generator DesignRevolving field, Self-ventilated, Drip-proof, Single bearing
Voltage Regulation (No Load to Full Load)±0.5 %
Power Factor0.8
Armature ConnectionStar with Neutral/ Zig Zag
ExcitationBrushless with AVR
No. Poles4-pole
Frequency60 Hz
Frequency Regulation (steady state load)±0.25 %
Sound Level (Full Load at 23 ft.)65 dB(A)
Engine SpecificationsMake/ModelIsuzu / 4HK1X
EmissionsEPA Tier 3 Certified
Starting SystemElectric
Design4-cycle, watercooled, direct injection, turbocharged, air to air intercooled
Gross Engine Power Output170.3 bhp127 kW
Fuel Tank Capacity169 gal640 L
Fuel Consumption:
Full load7.3 gph27.6 lph
3/4 load5.7 gph21.7 lph
1/2 load4.0 gph15.1 lph
1/4 load2.4 gph9.1 lph
Coolant Capacity5.2 gal19.7 L
Oil Capacity6.1 gal23.4 L
Battery12V 128 Ah x 1
TRLR150US Trailer SpecificationsGross Vehicle Weight Rating (GVWR)11,000 lb4,989.51 kg
Gross Axle Weight Rating (GAWR) (ea.)6,000 lb2,721.55 kg
Coupler Rating
Tire SizeST235/80R16 LR-E
Tire Load Rating (ea.)3,500 lb1,587.57 kg
Wheel Bolt Pattern8 Lug on 6.5 in
Fuel Tank Capacity180 gal681.37 L
Combined Tank Runtime:
100% Load23 h
Fits MQ Power Generator ModelsDCA125USI
DCA150USJ
TRLR150US Dimensions & WeightsOverall Length184 in4673.6 mm
Overall Width83 in2108.2 mm
Overall Height24 in609.6 mm
Operating Weight
Without Fuel1,772 lb445 kg
