Dejana Hub Drive Underground Cable Puller | Rent, Finance, or Buy

Dejana Hub Drive Cable Puller on 2012 Freightliner M2 106 Truck

Dejana Hub Drive Cable Puller on 2012 Freightliner M2 106 Truck
Product Specifications
BRAND  Dejana
MODEL  Hub Drive
EQUIPMENT CONDITION Used
CREDIT SCORE Good (670-739)
DESCRIPTION
Developed in close cooperation with public utility companies, these units offer a variety of features to increase capacity, provide trouble-free performance, and improve service life.The patented reel drive system is  unique in that it is all hydraulic with a direct drive crankshaft powered by two hydraulic cylinders on each arm. The hydraulic lifting cylinders are directly connected to the arms without any linkage providing less parts, less breakage, and longer service life. Both arms can deliver 200,000 inch-pounds of torque each (or a combined 400,000 inch-pounds of force), which means that using a 84” diameter reel, the drive system can pull up to 20,000 pounds.
ADDITIONAL INFORMATION
  • Year: 2012
  • Manufacturer: Freightliner
  • Model: M2-106
  • Condition: Used
  • Serial Number: Hub Drive Cable Puller
  • Stock Number: D1622
  • Mileage: 32400
  • Fuel type: Diesel
  • Transmission: Automatic
  • Chassis VIN: 1FVHCYBS8CDBD1622
  • Engine model: 8.3 L 505 CID L6 Cummins ISC Diesel
  • Brake type: Air
  • GVWR: 54600
  • Drive: 6x4
  • Body model: Reg Cab Utility Reel Loader
  • Under CDL: No
  • A/C: Yes
  • Cruise control: Yes
Chassis
  • 60,000 lbs. GVWR
  • 14,600 lbs. front axle capacity
  • 46,000 lbs. capacity rear axle, single speed, full floating
  • 224” wheelbase
  • 156” CT
  • 120,000-PSI inverted “L” frame reinforcement
  • Diesel engine, 250 HP, 800 lb/ft minimum
  • Allison automatic transmission, overdrive 6-speed
  • Engine-driven, water-cooled, air compressor
​Body Specifications
  • Heavy-duty steel platform body, all welded construction
  • Outside body dimensions: 95˝ W x 225˝ L
  • Long sill construction: 6˝ x 3˝ x ½˝ structural rectangular steel tubing
  • Cross sill construction: 6˝ structural steel on 12” centers
  • Body floor construction: 1/8” thick removable steel tread plate panels
  • Deck height: 58”
Hub Drive
  • Lift arm capacity:16,000 lbs. min.(32,000 lbs. on the deck)
  • Reel size capacity (diameter): 5’ to 9’
  • Reel size capacity (width): 40” to 72”
  • Reel rotational power: 400,000 inch-lbs. @ 10 RPM min
  • Hydraulic reel drivers
  • Hydraulically powered traversing lift arms, operated independently with lateral travel of 26” radial swing 160
