Clinic In A Can Relocatable Emergency/Trauma Unit

DESCRIPTION

The Premium 20 foot Clinic In A Can containerized medical clinic.   The clinic is constructed and finished using the exact same material as all of our clinics offerings, which is our standard.   The Premium clinic comes with both keyed-lockable floor and wall medical storage cabinetry, 24 inch deep counter-top work space with integrated stainless steel sink and functioning bug screened window.   This unit is telemedicine ready with integrated Cat5, COAX & Telephone ports which can be easily be connected to a hardwired or satellite provider.

When coupled with one of our solar systems, this unit design is ideal for working in austere enviornments in an area withou established utilitiy infrastructure like; water, sewer or electricity.    For example: a natural disaster, infectious disease outbreaks, concerts, soccer tournaments or any large gathering requiring an autonomously functioning medical facility.



ADDITIONAL INFORMATION

Key Features

• Fast Turn-Around

These clinics can be deployed immediately as opposed to the extended time and effort it takes to build a clinic on site

• Ready to Use

When your clinic is delivered, it is completely equipped and ready to use.

• Economical

We can build a fully equipped, high-quality clinic at the fraction of the cost of on-site construction.

• Durable

Our clinics are a dependable solution for your medical care needs.  Since our clinics are made from steel containers, they can withstand extreme weather conditions, earthquakes, harsh terrain and security threats.  Life expectancy of our clinics is 20 - 30 years.

• Environmentally Friendly

We use recycled shipping containers and materials to build our clinics.  We also offer the customized option of solar energy powered clinics.

• Infection Control Compliant

Armstrong Medical Grade seamless vinyl flooring with flash coving, Midmark Medical Cabinets, Parkland Plastic NRP-FR walls and ceilings and recessed electrical outlets meets and exceed EU and U.S. health code standards and can be cleaned with all bactericidal, fungicidal and virucidal solutions.

• Climate Controlled

The extremely well built structure with R-19 insulation combined with a super energy efficient Daikin 9000 BTU 25 SEER D/C inverted heat pump creates a cost effective, environmentally controlled work area even in the harshest of hot or cold environments.

• Solar Powered Clinic Option

Your clinic will run 24 hours/7 days per week totally on solar power.   The average power consumption of the clinic including our air condition is less than 300 watts.   Your clinic can be set in the most remote location and provide life saving medical attention regardless of the surrounding infrastructure.    Even if the weather is rainy or overcast, your solar powered clinic will continue to provide power through the back-up battery system for upwards of 18 hours with all equipment running normal.  If it is only lights and basic medical equipment (without air conditioning) your clinic will have 36 hours of back-up power


CONSTRUCTION PROCESS:

• Midmark Renew Style steel pressed, powder coated base and 24” tall wall cabinets with integrated locks, stainless steel sink and gooseneck faucet, trash can with integrated trash door
• (1) Daiken 19 SEER high efficiency 9000 BTU D/C Inverted split air conditioner unit with integrated heat pump.
• 5 inches of open cell 1/2lb Icynene foam insulation sprayed in the walls and ceiling resulting in a total R-Value of 19 or RSI of 3.34
• Interior walls framed with 3 inches 20 gauge galvanized steel structural studs.
• Rough plumbing is 1/2 inches PEX tubing with brass fittings
• Armstrong Medley Diamond 10 technology coating, Medical Grade seamless homogenous vinyl flooring with 4 inches of flash coving.
• Walls and ceilings are covered with a 0.55mm full-color thickness Non-FRP washable surface which has been pre-laminated to a 3/8 inch OSB board.
• (2) One Energy Efficient  2 ft X 2 ft flat-panel LED lighting per exam room for a total of (2) LED lights
• Rough electrical uses hospital grade UL listed metal clad 12/2 solid copper wires and galvanized metal boxes
• (6) hospital grade duplex electrical outlets.
• Communication & Telemedicine ready including (1) Cat 5 internal access point, (1) Coax, (optional) (1) Standard telephone with exterior communication port access panel
• Available in 110V or 220V 50/60 Hz options
• External water supply connection, external grey water waste connection
• 23 inch X 23 inch vinyl sliding glass UV window with integrated bug screen.
• CSC certified Container which has been painted with a two-part epoxy white which resists rust and reflects the suns heat.
• Finished Interior Usable Medical Space:  112 square feet or 10.57 sq. meters
• Medical Storage Space: 35 cubic feet or 1 cubic meter of medical storage space
• (1) 180cfm negative pressure exhaust fan for 12 air exchanges per hour.  (optional)
• (1) On demand under sink hot water heater (optional)
• ADA Compliant.

MEDICAL EQUIPMENT INCLUDED:

customized to client's needs though at an additional charge

--

Transportation fees not included in the above cost.   Check with local authorities to determine if containerized medical facilities are acceptable in their jurisdiction.

--

12-MONTH / 1-YEAR MINIMUM RENTAL TERM REQUIRED; customer will be required to pay all (12) Monthly Rental Payments to KWIPPED if an early rental termination request is submitted
