• 13,000 lbs. GVWR - Calculated at 15% Weight Transfer to Tow Vehicle
• 10,200 lbs. Load Capacity
DIMENSIONS
Length Adjustments: 20' / 25' / 30'
Cargo Bed: 9'L x 64"W x 15"H
Overall Width: 86"
Bolster Height: 42" (45" with Optional Removable Bolsters)
AXLES
• 6000 lbs. Tandem Straight Axles - (Optional Axles: 7K & 8K)
• Electric Brakes on All Wheels
• 3500 lbs. 5 Leaf Slipper Springs,
• Reinforced Spring Hangers with 3” Structural C-Channel Crossmembers
• (4) four - ST235/80R16 LR-E Tires, Capacity 3,042 lbs. each, Single Wheel Application
• (4) four - 16” x 6” Single Wheels (8 Hole on 6 1/2" Bolt Circle)
• (1) Pair - Mud Flaps
• (1) Pair - Fender Mounted Wheel Chock Holders (Wheel Chocks Not Included)
POLE BOLSTERS
• Front Bolster: 45”W Removable (Mounted on Extendable Tongue)
• Center Bolster: 64”W with Pole Stops (Built into Front Wall of Cargo Bed)
• Rear Bolster: 64” W with Pole Stops (Built into Tailgate - 2”x2” Tubular Construction)
• (4) four - Heavy Duty Ratchet Type Winch Binders with Breaker Bar
• (4) four - 15’ L x 4” W x 12000 lbs. Nylon Straps
• 6” x 4” x 1/4" Wall Extendable Tongue with Lubricated Steel Wear Pads
• 6-Position Adjustable Hitch Plate
• 2 1/2" Lunette Eye, 42,000 lbs. Capacity
• 3/8” x 36” Safety Chains with Safety Hooks and Anchor Shackles
A-FRAME & JACK
• 6” x 2” Tubular Steel A-Frame
• Fixed Binkley, Model 48000 Drop Leg Jack, 12,000 lb. Static Load Capacity
MAIN FRAME
• 6” x 3” Tubular Steel Main Frame
• 8” x 6” Receiver Tube
• 6” x 4“ Tubular Steel Crossmembers Under Center and Rear Bolsters
• 3” Structural C-Channel Crossmembers on 14 1/2” Centers Under Cargo Bed Floor
CARGO BED
• Interior Dimensions: 9’L x 64”W x 15”H with Reinforced Fold Down Tailgate
• Floor: 1/8” Smooth Steel Construction
• Sidewalls: 12 Gauge Formed in Brake for Added Strength
• Tailgate: Tubular Construction, w/ Offset Hinges so Debris is Easily Cleared
• (4) four - 5/8” D-Rings, 19,000 lbs. Capacity each, Floor Mounted (1) one each Corner
